TH400 Night Stalker Series 22-2,800 RPM GM Torque Converter Part Number 46012

GM TH350/TH400 Night Stalker Series Torque Converter

Achieve optimal power transfer and reliability with our high-performance Night Stalker Series Torque Converter, precision-machined for professional applications. Engineered specifically for the TH350 and fitting hoods of the TH400 (with proper Flex-Plate), this extreme duty converter delivers dependable performance, whether you are building a weekend cruiser or dedicated racing machine. Our rigorous quality control ensures durability and consistent operation in demanding driveshaft applications.

Product Specifications

• Series: Night Stalker Series
• Application Compatibility: Fits TH350 (Requires proper Flex-Plate for installation)
• Pump Pilot Size: 1.703 inch Crank Pilot
• Torque Converter Type: Modified Extreme Duty Stator
• Impeller Hub: Hardened Chrome Moley Impeller Hub
• Turbine Hub: 30 Spline Turbine Hub
• Construction Details: Precision CNC Machined, Torrington Style Incased Bearings
• Stall Range: 2,200 - 2,800 RPM
• Bolt Circle Diameter: Factory Specified at 12 inches (Core Bolt Circle: 11.5 inches)
• Bolt Specification: 10mm X 1.5 Pitch Threads Class 10 or Stronger
• Anti-Balloon Plate: Included (NO)
• Finishing: Four Corner Tac Welded Fins or Furnace-Brazed
• Testing Rigor: Leak & Pressure Tested, Digitally Balanced, Quality Inspections at Every Step

Performance Guidance

• Use Type F transmission fluid for best results when installing a Transmission Cooler.
• Apply Blue Loctite to ensure secure installation and prevent movement.

Installation Considerations

• All advertised stall speeds are based on a specific vehicle's setup and actual stalls will vary depending on your application. Please contact us for customized information.
• We recommend upgrading to a "Street Bandit Series" torque converter if you have upgraded two or more components (e.g., Intake, Heads, Headers, Exhaust, Camshaft, or Gearing).
• For applications involving power adders such as Nitrous Oxide (NOS), Turbochargers, Superchargers, or a Transmission Brake, we recommend upgrading to an "Out Law Racing Series" torque converter.

Building high performance and racing converters since 1970! Veteran owned and family run. Contact us today at (888) 267-7464 to discuss your specific drivetrain needs.
