Flexplate CHEVY 454/502 Gen V/VI 1991-97 168T 74180

OUT LAW Racing Series High HP Flexplate Assembly - CHEV 454/502 Gen V/VI

Elevate your build with this premium Out Law Racing Series Flexplate. Engineered for extreme performance, this assembly is designed to handle the high horsepower demands of your Chevy 454/502 Gen V/VI engine (1991-97). Utilizing a robust .187" thick core and accommodating a late model 6-bolt convertor pattern, this plate ensures maximum durability and reliable transmission function in competitive racing applications.

Ideal for transmissions such as the TH350 or POWERGLIDE TH400, this high-performance plate provides the perfect match for your extreme racing setup, maintaining rotational integrity under the most demanding conditions.

Key Product Details

• Series: Out Law Racing Series, SFI Rated
• Application: High HP Applications (Extreme Duty)
• Compatibility: CHEV 454/502 Gen V/VI (1991-97)
• Torque Converter Pattern: Late Model 6 Bolt pattern included
• Design Feature: External Balance (Ext Bal)

Technical Specifications

• Part Number: 74180
• UPC: 6-78118-74180-3
• Core Thickness: .187"
• Diameter (OD): 14.13 in
• Flexplate Bolt Kit: Includes Part #10021

Installation & Fitment

• Designed for TH350 and POWERGLIDE TH400 transmissions.
• Provides a robust interface between the engine flywheel and the transmission input shaft.
