200R 700R4 Night Stalker Series 22-2,800 RPM Lock Up GM Torque Converter Part Number 48402

GM Chevy 700R4/200R/298mm Torque Converter - Night Stalker Series (LT Engines)

Enhance your powertrain performance with this heavy-duty Night Stalker Series Torque Converter, specifically engineered for LT type GM Chevy transmissions (700R4/200R/298mm). Designed for reliable, high-performance use, this converter provides optimal power transfer and durability under extreme driving conditions. Manufactured with rigorous quality inspections and leak/pressure testing, it ensures exceptional performance both in racing and aggressive street applications.

This high-quality assembly includes a factory 12-inch core and is built to withstand the demands of your specific vehicle setup, offering a robust solution for achieving peak performance.

Key Specifications

• Transmission Type: 3-Step Input Shaft
• Part Number: 48402
• Series: Night Stalker Series
• Stall Range: 2,200 - 2,800 RPM
• Core Diameter: Factory 12 inch
• Bolt Circle Diameter: 10.75 inches
• Input Shaft Splines: 27 Tooth (Smaller splines count)
• Bearing Style: Torrington Style Incased Bearings
• Stator Design: Modified Heavy Duty Stator
• Lockup: Extreme Duty Lock Up
• Seals: Extreme Temp Heavy Duty O-ring
• Crank Pilot: Factory 1.703 inch Pilot
• Bolt Size: 10MM X 1.5 Pitch
• Additional Features: No Anti-Balloon Plates, Digitally Balanced, 4 Corner Tac Welded/Furnace Brazed Fins

Installation & Performance Guidance

• Use Type F Transmission Fluid for best operating results.
• Always use a transmission cooler to manage heat during high-stress operation.
• Apply Blue Loctite when assembling components for maximum reliability.

Important Considerations

• All advertised stall ranges are based on specific vehicle setups and may vary depending on your application. Contact us for personalized advice regarding installation or performance goals.
• For maximum durability and performance gains with modified drivetrains (upgraded intake, headers, exhaust, cam, or gearing), we recommend upgrading to a "Street Bandit Series" torque converter.
• If your application includes power adders such as Nitrous Oxide (NOS), Turbochargers, Superchargers, or a Transmission Brake, we recommend upgrading to our specialized "Out Law Series" torque converter.

MADE IN THE USA. Building High Performance & Racing Converters Since 1970!
