2004R 700R4 298mm Street Bandit 22-2,800 RPM Lock Up GM Torque Converter Part Number 48432

GM Chevy 700R4 Street Bandit Series Torque Converter - Part #48432

Elevate your drivetrain with our high-performance Torque Converter designed specifically for LT type GM Chevy applications. Built using a robust 9.6-inch core and featuring a hardened chrome molybdenum hub, this unit is engineered for dependable performance whether you are cruising or pushing your vehicle to its limits. The Street Bandit series delivers extreme duty lock-up and unmatched quality, ensuring smooth power transfer and durability under pressure.

Key Specifications & Construction

• Transmission Type: 700R4
• Series: Street Bandit Series
• Part Number: 48432
• Application: LT Type Engines (Ideal for 3 step Input Shaft)
• Stall Range: 2,200 - 2,800 RPM
• Core Size: 9.6 inch
• Bolt Circle Diameter: 10.75 inches
• Input Shaft Splines: 27 Spline (Count smaller splines per tooth)
• Hub Material: Hardened Chrome Moly
• Bearings: Torrington Style Incased Bearings
• Stator: Modified Heavy Duty Stator with Extreme Duty Lock Up capability.
• Crank Pilot: 1.703 inch precision CNC machined.
• Bolt Size: 3/8 X 16 TPI (Grade 8 hardware required).
• Design Features: Anti-Balloon Plates, No End of Input Shaft O-Ring required (leakage sealed on Turbine Hub), Digitally Balanced, Quality Inspected & Leak/Pressure Tested.

Product Features

• Made in the USA for superior quality control.
• Furnace brazed/Tac Welded fins provide exceptional thermal stability.

Operation Considerations

• Use Type F transmission fluid for optimal performance.
• Pair with an additional transmission cooler for sustained high-power use.
• Applying Blue Loctite is recommended, particularly for setups featuring choppy cams or lightweight vehicles.

Important Notes

• All advertised stall ranges are based on specific vehicle setups and may vary depending on your application. Please contact us for personalized advice regarding your build.
• For vehicles equipped with power adders (Nitrous, Turbocharger, Supercharger, or Trans Brakes), we recommend upgrading to an "Outlaw Series" torque converter.

For high-performance and racing torque converters since 1970, trust the experts. Build your performance dreams with us!
